TATU GCRO 7010 - Quality that others strive for
This is an outstanding primary pass machine with universal 10 ½” spacing. Ideally suited to all crops including sugarcane, rice and cotton. Can penetrate hard soils and will bury stubble exceptionally well.
Fitted with a new swivel type of oil bath bearings that further increases the lifetime of the machine. A hydraulic cylinder makes adjustment of the hitch position easy and hydraulic locking pins on wing folds ensures that when folded the wings are locked solid and doesn’t ride up.
TATU GCRO 7010 FOLDING FRAME OFFSET DISC 48 – 60 Specifications
| MODEL | DISCS | DISC SIZE | SPACING | AXLE | WORKING WIDTH | TRANSPORT WIDTH | WEIGHT | req hp | RRP EX GST |
|---|---|---|---|---|---|---|---|---|---|
| GRCO 7010 | 48 | 28" x 7.5mm | 270mm | 1 3/4" | 6.1m | 4.4m | 8,555kg | 280-320 | $122,000 |
| GCRO 7010 | 52 | 28" x 7.5mm | 270mm | 1 3/4" | 6.7m | 4.4m | 8,750kg | 300-320 | $125,500 |
| GCRO 7010 | 56 | 28" X 7.5mm | 270mm | 1 3/4" | 7.2m | 4.4m | 8,998kg | 320-350 | $128,700 |
| GCRO 7010 | 60 | 30" x7.5mm | 270mm | 1 3/4" | 7.7m | 5.2m | 9,350kg | 340-390 | $142,600 |
*Prices don’t include delivery, setup, or dealer charges. Prices exclude GST and can be changed without prior notice.*
TATU GCRO 7010 OFFSET DISC Features
Strong Disc Blades
The standard fitment of 28″x7.5mm scalloped discs should be the first clue that this machine will dig. Add the option of upgrading to 30″x7.5mm scalloped or plain discs will confirm it.
Disc blades are fitted on 270mm spacing which gives a great mix of depth and full cut out, leaving an amazing finish for such a big disc harrow.
Big Gang Axles
There is no point having big disc blades fitted up to a small axle as they will just break or bend. The GCRO 7010 doesnt lack in this area, having big 1 3/4″ round axles.
This means that you can confidently use the entire weight and depth of cut in the harshest conditions and know that the axles will handle it.
Big Oil Bath Bearings
To couple with strong disc blades & big axles are the huge Tatu OIL BATH BEARINGS. These are double taper roller bearings with Duo-Cone Seals.
And the best part of being Oil Bath bearings is that they do not need daily or even weekly greasing. They are basically maintenance free. Just check the oil level ever now and then!
Easy to setup & adjust, the gang aggressiveness can be adjusted by changing the front and rear angles. This also can assist with making the plough pull straight behind the tractor.
Other Features
- Easy to hook up with Chain & Spring assembly
- Outside Covering Disc that helps provide a level finish
- Jack stand & hydraulic adjustment on hitch position
- Oversize Sign & Rear tow hitch
- Large tyre package for easy and safe road transport
Tatu Swivel Bearing
TATU Swivel Oil Bath Bearings for low maintenance and long life.
