Farmet
Softer PS
Trailing
Increased resistance, compactness and versatility
The main advantage of the disc plough-harrow Softer is a universal usage from the first stubble breaking to subsequent pre-sowing preparation of the soil after the breaking or ploughing. The Softer is characterised with simple design with increased resistance, compactness and versatility with minimum adjustments and lubrication points plus excellent stability and precise deep guiding.
Disks with Dentate Circumference
Discs with the diameter of 510 mm / 560 mm are located in two rows. For the case of contact with an obstacle, each disc is separately effectively protected by means of rubber mounting.
The discs are placed in maintenance-free bearings with excellent service life. Optimum geometry of discs ensures high-quality work with very good productivity and high percentage of incorporated plant residues. The discs retain ideal working angle even with partially worn geometry of discs. The disc spacing of 24 cm ensures good free flow of plant residues.
Disks with the diameter of 510 mm / 560 mm located in two rows will undercut the soil. Working depth is 3,5-12 cm.
Clods are crumbled by the rear roller.
High-Strength Materials
High-strength refined materials used for crucial nodes to ensure long service life. Strongly dimensioned frame of high-strength steels.
Maintenance-Free Placement of Discs
Maintenance-free placement of the discs ensuring operation of the machine with no need of additional lubrication.
Maintenance-Free Rubber Mounting
Resistant and maintenance-free rubber mounting for adaptation to terrain with protection against overload.
Farmet | Softer PS Specifications
| Softer 4 FIX P | Softer 4.5 PS | Softer 5 PS | Softer 6 PS | |
|---|---|---|---|---|
| Working width | 4100mm | 4600mm | 5080mm | 6000mm |
| Transport height | 1600mm | 2650mm | 2900mm | 3370mm |
| Total machine length | 6675mm | 6675mm | 6675mm | 5740mm |
| Working depth | 35 – 120mm | 35 – 120mm | 35 – 120mm | 35 – 120mm |
| Number of disks – Front row | 17 | 19 | 21 | 25 |
| Number of disks – rear row | 17 | 19 | 21 | 25 |
| Diameter of disks | 510 / 560mm | 510 / 560mm | 510 / 560mm | 510 / 560mm |
| Working Performance | 4-6 ha/h | 4.5-6.8 ha/h | 5-7.5 ha/h | 6-9 ha/h |
| Towing vehicle1 |
110 – 160 kW 150-215 HP |
120 – 180 kW 160 – 240 HP |
130 – 190 kW 175 – 255 HP |
150 – 225 kW 200 – 300 HP |
| Working speed | 10 – 15 km/h | 10 – 15 km/h | 10 – 15 km/h | 10 – 15 km/h |
| Maximum transport speed4 | 20 km/h | 20 km/h | 20 km/h | 20 km/h |
| Maximum slope availability | 6° | 6° | 6° | 6° |
| Dimension of tyre – transport | 400/60-15.5 | 400/60-15.5 | 400/60-15.5 | 400/60-15.5 |
|
Number of hydraulic circuits/pressure3 | 2/200 BAR | 3/200 BAR | 3/200 BAR | 3/200 BAR |
| Number of hydrocouples/type3 | 4 / ISO 12.5 | 6 / ISO 12.5 | 6 / ISO 12.5 | 6 / ISO 12.5 |
| Tractor hitch requirement | TBZ cat. 3 | TBZ cat. 3 | TBZ cat. 3 | TBZ cat. 3 |
| Machine Weight2 | 3600kg | 4000kg | 4350kg | 4990kg |
| Softer 8 PS | Softer 9 PS W | Softer 11 PS6 | Softer 12 PS W | |
|---|---|---|---|---|
| Working width | 7650mm | 8650mm | 10880mm | 11880mm |
| Transport width | 3000mm | 4000mm | 3000mm | 4000mm |
| Transport height | 4000mm | 4000mm | 4000mm | 4000mm |
| Total machine length | 6850mm | 6850mm | 6520mm | 6520mm |
| Working depth | 35 – 120mm | 35 – 120mm | 35 – 120mm | 35 – 120mm |
| Number of disks – Front row | 31 | 35 | 45 | 49 |
| Number of disks – rear row | 31 | 35 | 45 | 49 |
| Diameter of disks | 510 / 560mm | 510 / 560mm | 510 / 560mm | 510 / 560mm |
| Working Performance | 8-12 ha/h | 9-13.5 ha/h | 11-16.5 ha/h | 12-18.1 ha/h |
| Towing vehicle1 |
200 – 300 kW 270 – 405 HP |
220 – 320 kW 295 – 430 HP |
245 – 370 kW 330 – 495 HP |
280 – 410 kW 380 – 550 HP |
| Working speed | 10 – 15 km/h | 10 – 15 km/h | 10 – 15 km/h | 10 – 15 km/h |
| Maximum transport speed4 | 20 km/h | 20 km/h | 20 km/h | 20 km/h |
| Maximum slope availability | 6° | 6° | 6° | 6° |
| Dimension of tyre – transport | 500/50-17 | 520/50-17 | 500/50-17 | 520/50-17 |
| Brake Type / Distribution | air / two-line | air / two-line | air / two-line | air / two-line |
| Required Pressure | 8.5 kPa | 8.5 kPa | 8.5 kPa | 8.5 kPa |
|
Number of hydraulic circuits/pressure3 | 3/200 BAR | 3/200 BAR | 3 (4)/200 BAR | 3/200 BAR |
| Number of hydrocouples/type3 | 6 / ISO 12.5 | 6 / ISO 12.5 | 6(8) / ISO 12.53 | 6 / ISO 12.5 |
| Tractor hitch requirement | TBZ cat. 3 | TBZ cat. 3 | TBZ cat. 3 | TBZ cat. 3 |
| Machine Weight2 | 6700kg | 7600kg | 9200kg | 10920kg |
1 Recommended towing vehicle, the actual pulling force may significantly change according to the processing depth, soil conditions, inclination of land, wear of working members and their adjustment.
2 Machine weight with double roller.
3 Alternative of the hydraulic brake / operating pressure 130 ± 5 bar.
4 Valid for double rubber-tyred roller.
5 Transport / brake system: Follow national provisions valid for transport of machines on public roads. Verify legal provisions valid in the country, regulations on maximum allowable total weights and axle loads and also on necessary possible use of the brake system. If you have any questions, please contact our sales representative.
PS – half-carried foldable machine
Easy Operation
Due to minimum of adjusting and lubricating points the operation and subsequent maintenance are very easy steps that anybody can perform.
- Minimum of adjustment points.
- Minimum of lubrication points.
- No angles adjustments or translation of disks are needed.
Continuous Connection of Runs
The extreme disc is separately height-adjustable which allows continuous connection of runs.
Direction of the Processed Soil
The height and longitudinally adjustable side deflector for ideal direction of the processed soil.
Adjustment of Working Depth
Easy adjustment of the working depth according to the overview table using the distance washers on the roller piston rods.
