Farmet
Digger

Ripper

Deep Cultivation of Impermeable Soil

Digger is suitable especially as equivalent to standard ploughing at higher capacity and lower operating costs. It also is suitable for deep cultivation of impermeable layer of soil, levelling and fine processing of clods. It significantly improves absorption of compacted and wet soils and revitalizes headlands after harvest. It is also used for loosening of subsoil layer without risk of mixing with the biologically inactive soil.

Digger Technology

  • 1. Deep loosening zone and mixing of plant residues. Loosening depth 30 - 50 cm. The special shape of loosening chisels provides excellent penetration into the densely packed soils with very low traction resistance. The chisels are in two rows. In extreme conditions, only one row of chisels can be used to reduce traction resistance.
  • 2. Wave-levelling zone. Levelling discs also increase the effect of incorporating plant residues.
  • 3. Clod crumb and soil compaction zone. Optimum soil reconsolidation ensures good infiltration and soil moisture rise.
Farmet | Digger - DIGGER
Farmet | Digger - DIGGER

High Performance

  • The new tine design has a very low traction resistance and enables a high working speed up to 12 km/h.
  • Ploughshares smoothly penetrate the soil and the soil is cultivated without mixing it with subsoil layer, so-called biologically inactive soil.
  • Possibility of lifting one row of the tines under heavy conditions such as marshes, headlands or when ploughing roads after harvest.
  • Two rows of tines provide a very good stability of the machine and precise depth guiding without the need to use tracing wheels. The high frame clearance of 750 mm provides excellent passability.
Farmet | Digger - DIGGER

Robust Design

  • High-strength refined materials used for crucial nodes to ensure long service life.
  • Strongly dimensioned compact and carried frame.
  • The ploughshares are fitted with plates of cemented carbides for long service life.
Farmet | Digger - DIGGER

Protection of Ploughshares

The ploughshares are hydraulically protected by a release force at the tip of 1,100 kg or you can choose the variant with mechanical protection.

Farmet | Digger - DIGGER

Mechanical Protection of Ploughshares

The variant with mechanical protection of ploughshares – in case of too high resistance the cutting of the screw occurs.

Farmet | Digger - DIGGER

Prolonged Service Life of Ploughshares

The tips of ploughshares are fitted with plates of cemented carbides for long service life, low wear and to maintain optimum geometry.

Farmet | Digger - DIGGER

Levelling Discs

The levelling discs direct the processed soil in front of the rear spiked rollers and at the same time provide precise furrow levelling.

Farmet | Digger - DIGGER

Roller

The rear double spiked roller for fine processing of clods maintains the quality of the soil as in the presowing preparation in minimizing technologies or as the basic autumn soil processing for spring crops.

Farmet | Digger - DIGGER

Ploughshares

The ploughshares with winglets incorporate plant residues very well and the levelling discs together with the double spiked roller perfectly level furrows.

Easy Operation

Farmet | Digger - DIGGER

Adjustment of Depth

Easy working depth setting using tipping pads. When in the working position, the machine rests against the rear double spiked roller.

Farmet | Digger - DIGGER

Adjustment of the Disc Height

The height of the levelling discs is set automatically using a parallelogram of the rear roller attachment. The handles for mechanical setting are used for precise tuning.

Farmet | Digger - DIGGER

Hydraulic Control of Discs

To increase comfort of operator, the machine can be equipped with hydraulic control of the levelling discs. (optional)

Farmet | Digger - DIGGER

Setting of the Down Pressure

Simple mechanical setting of the down pressure of the first row of the double spiked roller. The down pressure regulates the intensity of clod crumbling. The roller is equipped with maintenance-free bearings with high level of covering.

Farmet | Digger - DIGGER

Slight Lifting of Ploughshares

For locally more compacted soils the front row of ploughshares can be lifted a little bit and thus the traction resistance of the machine can be temporarily lowered. The slight lifting of ploughshares is advantageous also for simple cleaning of the space among ploughshares.
Farmet | Digger - DIGGER

Position of Winglets

The vertical position of winglets can be adjusted in three positions and thus obtain optimum incorporation of plant residues for various depths of processing.

Farmet | Digger - DIGGER

Side Deflectors

For more precise connection of runs the machine can be equipped with side deflectors with adjustable height that automatically copy terrain.

Farmet | Digger - DIGGER

Ball Valves

To facilitate disconnection of hydraulic circuits of ploughshare protection, these circuits are during machine shutdown equipped with ball valves.

Farmet | Digger Specifications

3N 4N
Working width 2900mm 3900mm
Transport width 2900mm 3990mm
Transport height 1790mm 1790mm
Total machine length 3520 – 4000mm 3520 – 4000mm
Working depth 250-500mm 250-500mm
Number of ploughshares 7 9
Distance between ploughshares 425mm 425mm
Number of ploughshare rows 2 2
Pitch of rows 950mm 950mm
Width of ploughshare with winglets 75 / 295mm 75 / 295mm
Frame clearance 750mm 750mm
Working Performance 2.4 – 3.6 ha/h 3.1 – 4.7 ha/h
Towing vehicle1 180-270 kW
240-360 HP
240-360 kW
330-450 HP
Working speed 8-12 km/h 8-12 km/h
Maximum transport speed2 25 km/h 25 km/h
Maximum slope availability 11° 11°
Tractor hitch requirement TPH cat. 3 and 4 TPH cat. 3 and 4
Machine Weight 2200-2800 kg 2900-3700kg

3 Fert+ 4 Fert+ 3 Fert+ Compact 4 Fert+ Compact
Working width 2900mm 3900mm 2990mm 3990mm
Transport width 2990mm 3990mm 2990mm 3990mm
Transport height 2790mm 2790mm 3500mm 3500mm
Total machine length 3520 – 4000mm 3520 – 4000mm 3645 – 4125mm 3645 – 4125mm
Working depth 250 – 500mm 250 – 500mm 250 – 500mm 250 – 500mm
Hopper Capacity 2000L 2000L
Fertiliser Batch Size 70-300kg/ha 70-300kg/ha
Number of ploughshares 7 9 7 9
Distance between ploughshares 425mm 425mm 425mm 425mm
Number of ploughshare rows 2 2 2 2
Pitch of rows 950mm 950mm 950mm 950mm
Width of ploughshare with winglets 75 / 295mm 75 / 295mm 75 / 295mm 75 / 295mm
Frame clearance 750mm 750mm 750mm 750mm
Working Performance 2.4 – 3.6 ha/h 3.1 – 4.7 ha/h 2.4 – 3.6 ha/h 3.1 – 4.7 ha/h
Towing vehicle1 180 – 270 kW
240 – 360 HP
240 – 360 kW
330 – 450 HP
180 – 270 kW
240 – 360 HP
240 – 360 kW
330 – 450 HP
Working speed 8-12 km/h 8-12 km/h 8-12 km/h 8-12 km/h
Maximum transport speed2 25 km/h 25 km/h 25 km/h 25 km/h
Maximum slope availability 11° 11° 11° 11°
Tractor hitch requirement TPH cat. 3 and 4 TPH cat. 3 and 4 TPH cat. 3 and 4 TPH cat. 3 and 4
Machine Weight 2250 – 2850kg 2950 – 3750kg 2860 – 3460kg 3800 – 4600kg

3 N-P Fert+ Compact 4 N-P Fert+ Compact
Working width 2990mm 3990mm
Transport width 2990mm 3990mm
Transport height 3500mm 3500mm
Total machine length 7720mm 7720mm
Working depth 250 – 500mm 250 – 500mm
Hopper Capacity 2000L 2000L
Fertiliser Batch Size 70-300kg/ha 70-300kg/ha
Number of ploughshares 7 9
Distance between ploughshares 425mm 425mm
Number of ploughshare rows 2 2
Pitch of rows 950mm 950mm
Width of ploughshare with winglets 75 / 295mm 75 / 295mm
Frame clearance 750mm 750mm
Working Performance 2.4 – 3.6 ha/h 3.1 – 4.7 ha/h
Towing vehicle1 220 – 330 kW
300 – 450 HP
265 – 400 kW
360 – 540 HP
Working speed 8-12 km/h 8-12 km/h
Maximum transport speed2 20 km/h 20 km/h
Maximum slope availability 11° 11°
Tractor hitch requirement TPH cat. 3 and 4; lower hitch K80; eye Ø 50, 70 mm TPH cat. 3 and 4; lower hitch K80; eye Ø 50, 70 mm
Machine Weight 6900 – 7500kg 7900 – 8700kg

1 Recommended towing vehicle, the actual pulling force may significantly change according to the processing depth, soil conditions, inclination of land, wear of working members and their adjustment.
2 Machine weight with double roller.
3 Alternative of the hydraulic brake / operating pressure 130 ± 5 bar.
4 Valid for double rubber-tyred roller.
5 Transport / brake system: Follow national provisions valid for transport of machines on public roads. Verify legal provisions valid in the country, regulations on maximum allowable total weights and axle loads and also on necessary possible use of the brake system. If you have any questions, please contact our sales representative.

PS – half-carried foldable machine
